The Asymmetric
P-Nylon filter
ABD09AND3EH1
ABD1AND3EH1
ABD09AND8EH1
ABD1AND3EH1
ABD09ANM8EH1 |
The Asymmetric P-Nylon filter utilizes the
proven defect-reducing Nylon membranes
configured into a new, asymmetric pore
geometry. This tapered pore design, with
an open upstream structure and a fine
downstream region, enables extremely low
operating pressures. The Nylon Effect1,
which has proven to significantly reduce
microbridge and cone defects in 193 nm
resist and BARC chemistries can now be
applied to all lithography applications. |
 |
|
Emflon PFA Filter Cartridges
AB1 PFA7 PVH4
AB2 PFA7 PVH4
AB3 PFA7 PVH4 |
Emflon PFA Filter Cartridges
Emflon PFA filters are a further addition to the successful Emflon filter range. The filters contain a proprietary pleated hydrophobic PTFE membrane and are designed for the removal of micro-organisms and particles from air and gases. |
 |
Emflon PFR Sterile Air Membrane Cartridges
AB05PFR2PVH4
AB1PFR7PVH4
AB2PFR7PVH4
AB3PFR7PVH4 |
Emflon PFR filters have been developed from the successful Emflon filter range launched in 1981 and widely used as air and gas sterilizing filters in the pharmaceutical and biotechnology industries. The double ayer PTFE membrane is inherently hydrophobic, chemically inert and designed specifically for removal of contaminating bacteria and viruses. Emflon PFR filters meet the ever increasing demand for air filters with greater strength, longer life and the ability to withstand the rigours of in-situ steaming in the forward or reverse direction. |
 |
|
Fluorodyne EX EDF Membrane Filter Cartridges
AB1UEDF7PH4
AB2UEDF7PH4
AB3UEDF7PH4
|
Fluorodyne EX EDF Membrane Filter Cartridges Fluorodyne EX grade EDF filter cartridges are high flow, high capacity sterilizing grade filters that can be steamed under wet or dry conditions. The filters have been optimized for performance with a built-in proprietary polyethersulfone (PES) prefilter over a polyvinylidinedifluoride (PVDF) membrane. Cartridges are constructed with Ultipleat technology to yield higher flow rates and maximize throughput. These filters are suitable for the filtration of a wide range of fluids including buffers, biological fluids, tissue
culture media and ophthalmic products. |
 |
|
Fluorodyne II DFL Membrane Filter Cartridges
AB1DBL7PH4
AB2DFL7PH4
AB3DJL7PH4
|
Fluorodyne II DFL Membrane Filter Cartridges
This validated 0.2 μm rated sterilizing grade filter retains Brevundimonas diminuta (ATCC 19146 at 107 cfu/cm2 EFA, LRV > 11) and demonstrates very low extractables and adsorption. It is recommended for sterilizing filtration of pharmaceutical solutions including active ingredients, biologicals and biotech proteins, ophthalmics and other dilute preservative solutions. |
 |
|
For Beverage Applications
AB1FF7WH4
AB2FF3WJ
AB3FF8WH4
AB4FF7WJ
AB1FF3WJ |
The Fuente water filter is designed to meet the highest requirements of water bottlers for removal of particles,cysts, oocysts and bacteria in water filtration applications. It is a 0.2 μm polyethersulfone membrane filter utilizing the unique Ultipleat? construction. Fuente filters last longer and provide high quality water at the lowest cost of ownership. |
 |
|
For clear, fresh and cold stabilized beer
AB1BB7W H32
AB2BB6W H32
AB3BB26W H32
AB4BB7W H32
AB1BB26W H32 |
For clear, fresh and cold stabilized beer
The new Pall BB Final Beer filter cartridges have been especially designed and qualified for the brewing industry for secure and
reliable removal of harmful beer spoilage microorganisms. The Supor medium is a highly efficient polyethersulfone membrane which, in combination with the construction of the BB Final Beer filter, ensures excellent service life and filtration results. |
 |
|
The Mega-Etch filter
EBC 050 10 M3V
EBC 100 20 M7V
EBC 200 10 M8V
EBC 450 20 M3V
EBC 050 10 M7V
|
It is targeted for use in recirculating etch baths. Utilizing ourpatented asymmetric polysulfone mem-brane enables the Mega-Etch filter toprovide the following benefits
EBC 050 10 M3V
EBC 100 20 M7V
EBC 200 10 M8V
EBC 450 20 M3V
EBC 050 10 M7V |
 |
| Reliable and inert Filters
419 A021W031SP
419 A045W072EP
419 A065W083VP |
Reliable and inert The new Pall Membracart XL II filter cartridges have been
especially developed and validated for the beverage industry for a secure and reliable removal of harmful microorganisms. The filter medium is a highly efficient
polyethersulphone membrane which, in combination with the construction of the Membracart XL II filter, ensures excellent service life and filtration results. |
 |
| Starclear Filter Cartridges
AB 1MAZ7 PJ
AB 2MAZ3 PH15
AB 3MAZ2 PJ |
Starclear Filter Cartridges
Starclear filters employ a unique composite design that incorporates a polypropylene pre-filtration layer (Pall Profile Star media) with 2 layers of 1 m absolute rated positively charged glass fiber filter membrane (Pall Ultipor GF Plus media). |
 |
Sterile Air Membrane Cartridges
FA71RPFWH4
FA72RPFWH4
FA73RPFWH4 |
Sterile Air Membrane Cartridges
The Pall Emflon PFW Final Air Filters are
designed for fermenter inlet air and
exhaust venting, sterile process air and
sterile venting of tanks in food processes.
FA71RPFWH4
FA72RPFWH4
FA73RPFWH4 |
 |
| |
|
|
