DUO-FINE E Series
DFN0.24US***.......
DFN1-10AN-**-*
DFN3-19.5UE-**-*
DFN10-20AV-**-*
DFN30-30UT-**-* |
Longer Service Life 304 Stainless Steel Center Core and End Caps Available
for High Temperature Applications
Small Diameter Fibers Ensure High Flow Rates at Low Pressure Drops Economical Alternative to Stringwound Cartridges Available in Retention Ratings of 0.2 to 50 microns (μm) Protective Netting is Color-Coded for Easy Identification of Micron Ratings End Configurations to Fit Most Housings Core Material Options for Different Temperature |
 |
DUO-FINE GT Series
DFGT3-10US-DOE
DFGT3-20UN-M3
DFGT3-27UE-DOC
DFGT3-30UV-M3
DFGT3-36US-DOE
DFGT3-40UE-M3
DFGT3-36UV-DOE |
Protects Critical Components From Abnormal Wear by Removing Harmful Contaminants Extends Lubricant Life Cycles and Lowers Regular Maintenance Costs High Surface Area Provides Significantly Higher Contaminant Holding Capacity than Wound or Sock Type Filter Cartridges Rigid Pleat Structure Withstands High Differential Pressures During System Start-Up Available in Standard Lengths to Retrofit Most Competitive Housings |
 |
|
DUO-FINE II Series
DFNT1-4US-**-*
DFNT1-10UN-**-*
DFNT1-20UE-**-*
DFNT1-30UV-**-*
DFNT3-39UT-**-*
DFNT10-40UM-**-*
DFNT30-9.75UW-
DFNT50-19.5UX-** |
DUO-FINE II Series
Superior Filtration Performance
More Economical Than Depth Type CartridgesExcellent Classifying Filter
Optional 100% Bubble Point Testing
Rigid Polypropylene Outer Cage Protects Filter Media in Harsh Operating Environments Available with Extended Core Imprinted for Easy Identification
Excellent Chemical Compatibility |
 |
|
DUO-FINE P Series
DFPT1-10ES-DOE
DFPT1-20EN-DOE
DFPT1-30EE-DOE
DFPT3-10EV-M3
DFPT10-40ET-DOE
DFPT30-20ES-M8
DFPT50-30EV-DOE
DFPT0.2-40EE-DOE
DFPT50-10EV-M3 |
DUO-FINE P Series
High Surface Area Pleated Cartridges Combine Excellent Retention Characteristics with High Contaminant Holding Capacity Polyester Hardware Provides Excellent Compatibility Available in Retention Ratings of 0.2 to 50 μm Thermal Bonding Eliminates Epoxies, Adhesives and Glues Manufactured Under ISO 9001 Quality System |
 |
|
Emflon PF FilterAB1F1003EH14
AB1F0503EH14
AB1F0103EH14
AB04F0023EH1
MPF2230F002EH1
MPF4463F002EH1
MPF4463F002EH1
MPF4463F002EH11
MPF2230F001EH1 |
Emflon PF Filter The Emflon PF filter is an all fluoropolymer cartridge, utilizing pleated filter medium for the filtration of aggressive process fluids.
|
 |
|
Epocel Series
PUY1ECH13
PUY2EEH
PUY3EGJ
PUY4ECH
MCS 1001ECH13
MCS 1001EEH
MCS 1001EGJ
MCS 4463 ECH13
MCS 4463 ECH
MCS 4463 ECJ |
Epocel Epoxy Impregnated Cellulosic Media with a Fixed Pore Construction Eliminates Unloading and Media Migration Broad Chemical Compatibility Recommended for Use with a Wide Range of Fluids and Gases Including Photographic Emulsions and Developer Chemicals, Lube Oil, Printing Inks, Air, Nitrogen, Ammonia and Natural Gas Not Recommended for Food or Pharmaceutical Applications |
 |
Marksman DFN Series
DFNMS3-1UN-PFB
DFNMXS10-2UE-PFB
DFNMS20-4UV-PFB
DFNMXS1.5-1UN-PFB
DFNMS20-2UE-PFB
DFNMS40-4UV-PFB |
Marksman DFN Series
New, larger cartridge geometry High flow capacity Inside-out flow traps contaminant inside the element Available to fit most Size 1 and Size 2 bag housings with no hardware changes Available in 40" (101.6 cm) for use in unique 40" (101.6 cm) Marksman housings Unique sealing device adjusts to fit in most bag filter housings High surface area for long service life Micro-fiberglass Duo-Fine media (with acrylic binder) Polypropylene end caps, polyester support and outer netting Wide chemical compatibility Short length option to accommodate shorter baskets |
 |
|
PallCell
AB 1DC3.8H4
AB 2DE7H
AB 3DG7J
AB 4DC3.8H
PUY 1DCJ
|
PallCell filters have a pleated high area construction for long service life. They are constructed of pure 100% cellulose
medium, having no resin binders, with polypropylene hard-ware. Since the components are cellulose and FDA listed polypropylene (approved for use in contact with wet foods),PallCell filters are recommended for clarification of such fluids as: deionized water, electronic grade solvents, fine chemicals,pharmaceuticals, liquid sugars, syrups and cosmetic formula-
tions. PallCell cartridges do not unload or exhibit media migration. |
 |
Poly-Fine II Filter Cartridge
PFTO2 10UEM712
PFTO5 20UTM712
PFTO2 10UTM712 |
Poly-Fine II Filter Cartridge
Manufactured for use under GMP
Supplied with a ＾Q￣ Certificate of Quality Lot traceable Manufactured from FDA listed materials per 21 CFR Components meet the specifications for biological safety as per the USP for ClassVI-121 ＜ C plastics (gaskets/O-rings excluded) Free from adhesives, binders and resins |
 |
|
POLY-FINE XLD Series
XLD1.5-4US-M8-NET
XLD3-10UN-M8-NET
XLD10-4UV-M8-NET
XLD4.5-20UE-M8-NET
XLD20-40UT-M8-NET
XLD40-9.75UF-M8-NET
XLD70-39UX-M8- |
POLY-FINE XLD Series Proprietary Gel Guard Filter Media Innovative Merger of Depth and Pleated Technologies High Surface Area for Long Service Life Micro Denier Melt Blown Fibers for High Efficiency Filtration High Flow Rates with Low Pressure Drops All Polypropylene Construction Absolute Rated at >99.9% Efficiency With Retention Ratings from 1.5 to 90 μm Highly Consistent, Reproducible Performance |
 |
Profile Star filters AB1A00825J
AB2A00825J
AB1A0103J
AB2A0153J
AB1A0153J
AB1A0303J
AB2A0303J
AB1A0503J
AB2A0103J
AB1A01003J
AB2A01003J
AB1A02003J
AB2A02003J |
Profile Star filters are pleated, depth all
polypropylene filters ideally suited for the removal of agglomerated particles and gels from slurries used in the chemical mechanical polishing (CMP) of oxide,tungsten and copper.
|
 |
|
Quantum P Series
QMPT002-975US-M3-B
QMPT005-100US-M3-B
QMPT010-195US-M3-B
QMPT020-200US-M3-B
QMPT030-270US-M3-B
QMPT050-292US-M3-B
QMPT100-300US-M3-B
QMPT300-395US-M3-B
QMPT002-400US-M3-B |
Quantum P Series Melt blown polypropylene filter medium provides efficient particle removal, high contaminant-holding capacity and wide chemical compatibility Available in retention ratings of 0.25 to 30 micron (μm) Protective netting is color coded for easy identification Small diameter fibers provide high flow rates at low
pressure drops Manufactured under an ISO 9001 quality system
|
 |
Small Flow Emflon filter MDY2230FNEHF
MCY4463FNEHF
MDY2230FREHF
MCY4463FREHF
MCY4440FREHF
MDY2230FTEJ
MCY4463FNEHF
MCY440FREHF
MCY9106FREH
MCY9112FREH
MCY9130FREH
MCY9163FREH |
The Small Flow Emflon filter is recom-
mended for chemicals which are com-
patible with PTFE and polypropylene.
Small Flow Emflon Filter
|
 |
|
Ultipor HT Series
HT0644GK010G
HT0644GK100H
HT0644GK200G
HT0644GK700H
HT0644GK100G
|
Ultipor HT filters have a pleated, high area construction for long service life. The unique medium structure consists of a high temperature binder resin which coats the fine glass fibers.The filter¨s materials of construction are qualified for uses up to 425＜F (218?C) with compatible fluids. The double open ended filters are installed over a tie rod/seal nut assembly. The flow pattern is outside to inside. |
 |
| |
|
|
| |
|
|
